Ball-Lok® Quick Release Pins

To configure a part number, click on the link below:

Double Acting Ball-Lok® Quick Release Pins

Double Acting Ball-Lok® Quick Release Pins are positive locking that require a push or pull of the button to release the balls. Standard and Metric sizes available.

To configure a part number, click on the link below:

• Double Acting Ball-Lok

Detent Ball-Lok® Quick Release Pins

Detent Ball-Lok® Quick Release Pins are non-positive locking that  pushes in and pulls out of the application with spring-loaded balls performing the impedance lock. Standard and Metric sizes available.

To configure a part number, click on the link below:

• Standard Sizes

Marine Pins

Marine Pins are Single Acting and Detent Ball-Lok® Quick Release Pins made of non-corrosive stainless steel made for marine applications.

To configure a part number, click on the link below:

• Marine Pins

Alignment Pins

Alignment Pins are used on doors, racks, and panel assemblies to align connector contacts, eliminate shear load damage to contacts and door assemblies, and to guide doors and panels to their proper position.

Receptacles

Receptacles provide locking for our Single Acting Ball-Lok® Quick Release Pins in blind applications and other applications when the parent material needs a hardened surface for the balls to lock against. A spring loaded plunger fills the hole preventing contamination when the quick release pin is not engaged. Receptacles can be riveted, threaded, or potted in place.

To configure a part number, click on the link below:

• Standard Receptacle
• Lightweight Receptacle
• Mounting Plate

Attachments

Attachments include lanyard and chain assemblies which can be connected to quick release pins to keep the pins permanently attached to the application. Warning Streamers are used with quick release pins in critical applications.

Wheelchair Axle Pins and Parts

Customizable wheelchair axle pins and parts.
